Aluinum Conductor Aluminum Alloy Reinforced

1.improved strength to weight ratio 2.better mechanical properties 3.improved electrical characteristics 4.excellent resistance to corrosion

Introduction Interrelated Quotation

Tel:+86-371-6676-6667 / E-mail:sales@hlcables.com

Introduction

ACAR(Aluinum Conductor Aluminum Alloy Reinforced)

Aluminium Conductor Alloy Reinforced (ACAR) is formed by concentrically stranded wires of Aluminium 1350 on high strength Aluminium -Magnesium -Silicon(AlMgSi) alloy core. The number of wires of Aluminum1350 & AlMgSi alloy depends on the cable design. Though the general design comprises a stranded core of AlMgSi alloy strand, in certain cable constructions , the wires of AlMgSi alloy strands can be distributed in layers throughout the Aluminium 1350 strands.

ACAR has got a better mechanical and electrical properties as compared to an equivalent ACSR, AAC or AAAC. A very good balance between the mechanical and electrical properties therefore makes ACAR the best choice where the ampacity, strength and light weight are the main consideration of the line design. These conductors are extensively used in overhead transmission and distribution lines.

1. Applications

ACAR is mainly used as bare overhead transmission cable and as primary and secondary distribution cable. It is also suitable for laying across basins, rivers and valleys where special geographical teatures exist.

2. Construction

ACAR consists of aluminum alloy wire and aluminum wires. The aluminum wires are concentrically stranded around the steel wire.

3. Features

ACAR offers optimal strength for line design. Variable steel core stranding enables desired strength to be achieved without sacrificing ampacity. I is low cost for the line and large transmission capacity. In order to foster the prevention of corrosion, the non-oxidizing grease can be fully or partially applied to ACAR.

package:New Wooden drum,Steel Wooden Drum or according to customers' request

Huadong Cable Co.,Ltd is one of the biggest professional wire and cable manufacturers in China (Mainland), integrating the design, production, sales and service. The factory founded in 2005 and located in Yuezhuang Village, Xindian Town, Xinzheng City, occupying 8,000 square meters. Our annual product capacity is more than 10,000,000 kilometers.

Main products:
Bare stranded conductors, such as AAC, ACSR, AAAC, ACAR, aluminum clad steel conductor; 0.6/1KV aerial bundled cable (ABC Cable), different voltages of XLPE insulated cables, armored cables, control cables, rubber insulated cables, PVC insulated wires and cables, etc.

These cables can be used for power transmission in air, underground or industrial, such as power station, coal, railway, agriculture and estate.
